The industrial dust collector air tank, also known as an air reservoir or pressure stabilizing tank, is a core supporting component for dust removal equipment such as pulse bag filters and cartridge dust collectors. It is mainly used to store and stabilize compressed air, providing a steady and sufficient air source for pulse valve jet cleaning.
Product Description
Made of high-quality steel plates through welding, the air tank features a solid structure and excellent airtightness, capable of withstanding normal operating pressure. It ensures uniform and stable pulse cleaning force, avoiding pressure fluctuations that may affect dust removal performance.
Widely applied in industrial dust removal systems for metallurgy, building materials, chemical engineering, grain processing, woodworking and furniture industries, it is used together with pulse valves and jet pipes to improve cleaning efficiency, extend filter bag service life, and guarantee continuous and stable operation of the equipment.
Product Specifications
| Item | Specification |
|---|---|
| Product Name | Dust Collector Air Tank / Air Reservoir |
| Model | Customizable as per customer requirements |
| Material | Q235B / Carbon Steel / Stainless Steel |
| Working Pressure | 0.4–0.8 MPa |
| Design Pressure | 1.0 MPa |
| Volume | 20L / 30L / 40L / 50L / 80L / 100L / 150L / 200L |
| Outer Diameter | Φ219 / Φ273 / Φ325 / Φ400 mm |
| Wall Thickness | 3mm / 4mm / 5mm |
| Inlet Port | DN15 / DN20 / DN25 (G1/2", G3/4", G1") |
| Number of Outlet Ports | 2–24 pcs (Customizable) |
| Outlet Size | G1/2", G3/4", G1", G1-1/2" |
| Surface Treatment | Painting / Galvanizing / Sandblasting |
| Application | Baghouse Dust Collector, Cartridge Dust Collector, Pulse Cleaning System |
Customized production can be provided to meet different requirements of specifications, materials and sizes！
